RESIDENTIAL ELEVATOR
Savaria Elevator Orion
Light Commercial - No Machine Room Elevator
The Orion® traditional cab comes fitted with a fire-rated architectural white steel panel interior, or with optional raised panels in a variety of colors on a black or architectural white steel cab. Other features include attractive stainless steel handrail, call stations and car operating panel (COP) with digital floor indicators, and a white ceiling with four silver color trimmed pot lights.
Product Features
Standard specifications
For commercial limited use/limited application (LU/LA), or residential use (where code permits3)
Capacity: 1400 lb (635 kg)
Standard 2 stop operation can be increased to 6 stops2 over a maximum of 25 ft (7620 mm); higher travel available where code permits
Running speed: 30 ft/min (0.15 m/s)
Commercial-grade stainless steel hall calls, COP and handrail
Illuminated indicators for the cab operating panel and hall call stations
Automatic cab on/off lighting
Traditional cab design with architectural white fire-rated steel panel cab interior and ceiling
Two-speed steel cab doors with infrared closing sensors in black, architectural white or stainless steel (upgrade on classic cab); automatic landing doors are finished with primer
Safety features
• Emergency battery back-up for floor-specific lowering and interior lighting
• Alarm button and emergency stop key • Manual lowering
• Slack rope safety switch
• Safety brakes
• Overspeed valve (hydraulic) or overspeed governor (MRL)
Technical Specifications
